US-EPA Approved Gases, Particulate Monitor & Particulate samplers
Approved gas monitors for the continuous measurement of criteria pollutants and specific gas parameters concentrations in ambient air to provide reference measurement for the implementation of clean air national and international regulations as well as gas purity, quality control and industrial hazardous leakage monitoring.
APPLICATION:
- Continuous indoor and outdoor air quality monitoring
- Stationary and mobile AQMS laboratories
- Leakage detection in industrial applications
- Continuous emissions monitoring (CEM) by dilution
- Background, rural, urban or sub-urban, industrial, traffic, roadside studies
- Laboratory and field studies on pollution effects
Description:
All the analyzers have been fully eco-designed, with a special consideration to the environmental impacts of the product during its whole life-cycle.
The exclusive «inside the box» recyclable foam modular concept makes the product more robust, power saving, simpler to service and eco-friendly.
MAIN ADVANTAGES:
- Environmental friendly: Low carbon footprint / Over 95% of the analyzer can be recycled / Ultra low power consumption / Common electronic boards: optimized spare parts stock
- SmartStatusLight™ power button for status of operation (ON/OFF, Alarm, Maintenance required…)
- Economic, Easy and reduced maintenance
- Service Assistant inside
- Interactivity: Smart, connected instruments.
Parameters:
CO, CO2, NO, NO2, NOx, SO2, H2S, TRS, HC(Methane CH4& non Methane), O3, VOC, NH3, BTEX
PARTICULATE MONITORS & SAMPLERS
ß-ray attenuation Analyzer
Particle concentration measurement of PM10, PM2.5 and PM1 using the Standard Reference Method
Optical Particulates Monitor
Simultaneous and real-time optical measurement of all types of particles PM1, PM2.5, PM10 using a single TSP inlet.
Automatic Sequential / Particulate Sampler
Designed to automatically sample particulates on filters using a TSP, PM10, PM2.5 or PM1 inlet.
GAS MONITORS
Nitrogen Oxides Analyzer (Chemiluminescence)
CLD based analyzer offering superior metrological performances for NO, NOx and NO2 measurements in the range 0-1 ppm or 0-10 ppm
- Option: external module for NH3 monitoring (Max 1 ppm)
- Option: Built-in permeation bench with NO2 tube
UV Photometric Ozone Analyzer
Provides accurate O3 measurements in the range of 0 – 500 ppb to 0 – 10 ppm
- Option: internal O3 generator (span check)
IR-GFC Carbon Monoxide Analyzer
IR-GFC analyzer designed for high sensitivity monitoring of low CO concentrations in the range of 0-50ppm to 0-300 ppm
- Option: CO2 measuring module (max 2000 ppm)
UV Fluorescence Sulfur Dioxide Analyzer
Uses UV radiation to measure SO2, with excellent performance, for a range from 0-10 ppm to 0-1 ppm
- Option: module for H2S or TRS monitoring (max 1 ppm), special configuration for TRS measurements in CO2 matrix
- Option: Built-in permeation bench with SO2 tube
FID Hydrocarbons Total VOC Analyzer
Uses the principle of flame ionization detection to measure the concentration of hydrocarbons.
- Option: THC / CH4 / nmHC (Total Hydrocarbons, methane & non-methane hydrocarbons) converter
- Option: zero air internal generator
CAPS Spectrometry Nitrogen Dioxide Analyzer
Designed to provide the most accurate value for 0-1 ppm NO2 concentrations
- Option: Built-in permeation bench with NO2 tube
Gas Chromatography Volatile Organic Compounds (BTEX)
BTEX automatic analyzer based on gas chromatography (GC) coupled with a photo-ionization detector (PID) for 0-300 ppb measurements range (Benzene). Carrier gas: H2
- Option: up to 40 other VOC compounds (max 2000 ppm)
